Products Description
PTFE filled with bronze
Advantages:
☆ Reducing friction
☆ Lightweight and flexible
☆ Good lubricity
☆ Good wear resistance
☆ Good shock absorption
☆ Lond service life
PTFE Slideway soft belt is made from PTFE and filled with bronze powder, a type of polymer that is known for its exceptional strength and durability.
One of the key features of PTFE Slideway soft belt is its ability to provide high accuracy in all types of precision machine tools, such as CNC equipment and processing centers. This means that this material can deliver outstanding performance in even the most demanding applications, making it an ideal choice for the most advanced manufacturing processes.
Another great advantage of PTFE Slideway soft belt is its excellent friction and wear properties. This is largely due to the rich solid lubricant particles that are embedded within the guide bands, providing a smooth and fluid movement that helps to reduce wear and tear on the equipment. As a result, this material is highly resistant to abrasion and can last for a long time, delivering consistent performance under heavy use.
PTFE Slideway soft belts are widely used in various industries such as textiles, printing, paper-manufacturing, food, chemical engineering, woodworking, and many more. The use of these belts has greatly enhanced the precision and functionality of machines, making work easier, efficient, and accurate.
The use of PTFE Slideway soft belts has also improved the safety of machine tools. These belts are designed to reduce friction and prevent the machines from overheating, which minimizes the risk of accidents. Additionally, they are lightweight and flexible, which reduces the chances of injuries during maintenance and repairs.
Production process:
Technical Parameters:
|
Material type |
Color |
Density (g/cm3) |
Linear thermal expansion factor (x10-5) 40-120℃ |
Tensile Strength (Mpa) |
Elongation (%) |
Compressive strength (Mpa) |
Bending strength (Mpa) |
Impact strength without Notch (KJ/m2) |
Friction and wear properties (dry friction) |
|||
|
Coefficient of friction |
Wear scar width (mm) |
Wear loss (mm3) |
||||||||||
|
YT |
Blue |
3-3.5 |
7.5 |
＞13 |
110 |
30-40 |
25-30 |
＞15 |
0.16-0.21 |
＜6 |
6.3-10.1 |
|
Typical Application
☆ Maintenance of mechanical sliding guide
☆ Textile machines
☆ Precision machine tools
☆ Printing machines
☆ Common machine tools
|
Thickness (mm) |
Width (mm) |
|
0.5,0.8,1.1,1.4,1.5,1.7,2.0,2.5,3.0 |
100,200,300 |
|
Customized size is also acceptable. |
|
Our service and advantage
☆ Providing special dimensions
☆ Alternative of imported belts at favorable prices
☆ Good quality with fast delivery
Our exhibition
PTC, BAUMA, Hannover Messe etc.
Packing & Delivery
Thermal shrinkage film
By Express (FedEx, UPS, DHL, TNT, EMS, etc. )
--- Advantage: Fast (takes about 7 - 10 days in the delivery), door to door
This is especially useful for urgent shipments that need to reach their destination quickly. Though express delivery is a little expensive, it is worth the cost if time is a crucial factor.
By Air Transportation
--- Advantage: Fast (takes about 8 - 12 days), a little cheaper than Express.
Though it takes a little longer than express delivery, at around 8-12 days, it is still relatively quick. Additionally, air transportation is a little cheaper than express delivery. The only downside is that the receiver has to collect the goods from the airport.
By Sea (Ocean ) Transportation
--- Advantage: Much cheaper than Express or Air transportation.
Sea transportation is an excellent option for individuals and businesses that need to transport goods across long distances. With its cost savings and global coverage, it's an attractive alternative to other transportation methods.
