Products Description
Phenolic resin with synthetic fiber
Advantages:
☆ Low friction
☆ Low wear
☆ Simple fitting
☆ Ideal for large diameters
Phenolic fabric wear strips are a vital component in hydraulic applications, providing excellent guidance for pistons and piston rods. These strips are designed to absorb radial forces and protect the rod and cylinder from making metallic contact, ensuring the equipment functions at an optimal level.
With their exceptional durability and long-lasting performance, phenolic fabric wear strips are an ideal choice for use in industrial settings. They are wrapped in a coil, making them easy to handle and install, and can be cut to size according to the specific needs of the application.
Compound wear strips can withstand even the most challenging environments, providing reliable support for hydraulic equipment. They are available in a range of sizes, ensuring that there is always an option to suit the requirements of any hydraulic system.
Phenolic fabric wear strips are an essential part of any hydraulic application, delivering superior performance and reliability. Their robust construction ensures they can withstand even the toughest operating conditions, while their flexibility allows them to be easily integrated into hydraulic systems of all kinds.
Production process:
Technical Parameters:
|
Part NO. |
Material |
Color |
Density g/cm³ |
Tensile Strength MPa |
Ultimate Compressive Strength MPa |
Bending Strength MPa |
Rockwell Hardness HRM |
Coefficient of Friction |
Temperature ℃ |
|
|
Dry |
Oil |
|||||||||
|
PFC-6T |
Phenolic resin with synthetic fiber |
Light yellow |
1.2-1.4 |
≥40 |
≥320 |
≥80 |
80 |
≤0.40 |
≤0.12 |
-40~+130 |
Typical Application
☆ Wear rings, guide rings of hydraulic cylinders
☆ Construction machineries
☆ Mining machineries
☆ Maintenance
Our service and advantage
☆ We have rich experience in production, inspection, OEM etc.
☆ Factory competitive prices
☆ Factory fast delivery
☆ Providing high quality products
☆ Providing free samples for testing
Our exhibition
PTC, BAUMA, Hannover Messe etc.
Packing & Delivery
By Express (FedEx, UPS, DHL, TNT, EMS, etc. )
--- Advantage: Fast (takes about 7 - 10 days in the delivery), door to door
This is especially useful for urgent shipments that need to reach their destination quickly. Though express delivery is a little expensive, it is worth the cost if time is a crucial factor.
By Air Transportation
--- Advantage: Fast (takes about 8 - 12 days), a little cheaper than Express.
Though it takes a little longer than express delivery, at around 8-12 days, it is still relatively quick. Additionally, air transportation is a little cheaper than express delivery. The only downside is that the receiver has to collect the goods from the airport.
By Sea (Ocean ) Transportation
--- Advantage: Much cheaper than Express or Air transportation.
Sea transportation is an excellent option for individuals and businesses that need to transport goods across long distances. With its cost savings and global coverage, it's an attractive alternative to other transportation methods.
Dimensions:
|
Width (mm) |
Thickness (MM) |
|
5.5 |
2 |
|
6.1 |
2 |
|
9.5 |
2 |
|
14.8 |
2 |
|
19.5 |
2 |
|
24.5 |
2 |
|
29.5 |
2 |
|
5.5 |
2.5 |
|
6.1 |
2.5 |
|
9.5 |
2.5 |
|
14.8 |
2.5 |
|
19.5 |
2.5 |
|
24.5 |
2.5 |
|
29.5 |
2.5 |
|
40 |
2.5 |
|
9.5 |
4 |
|
14.8 |
4 |
|
19.5 |
4 |
|
24.5 |
4 |
|
40 |
4 |
