Products Description

K513 Hydraulic Rod and Piston Seals

Advantages:

☆ Flexible for simple installation

☆ Excellent resistance to abrasion

☆ Positive lip actuation

☆ Kinfe trimmed precision sealing lips

☆ Insensitivity to shock and pressure peaks

☆ Wide range of sizes

product-888-378

The K513 is a good solution for hydraulic rod and piston seal applications. These seals feature a symmetrical squeeze design that ensures superior performance and longevity. The rectangular cross section of the seal guarantees the stability of the gland, providing reliable protection against leaks and other issues. Additionally, the sharp hypotenuse of the seal is expertly trimmed using precision trimming equipment, ensuring that it fits perfectly and works as intended.

Overall, the K513 Hydraulic Rod and Piston Seals are a reliable and effective solution for a wide range of sealing applications. Their high-quality construction and precise engineering ensure that they will provide excellent performance for years to come.

The K513 seal can be used as a separate seal or in series with a buffer seal. In piston applications, the model will function as a one-way seal. This model cannot be installed back to back and pressure traps may occur under bidirectional forces.

Production process:

Injection molding

product-1375-386

product-1534-337

Operating conditions

Maximum speed	≤1.0m/s
Temperature range	-45℃+110℃
Maximum pressure	≤400bar

Surface roughness	μmRa	μmRt
Dynamic sealing face ød	0.1＜＞0.4	4 max
Static sealing face øD₁	1.6 max	10 max
Static housing faces L₁	3.2 max	16 max

product-3005-451

Фd1	ФD1	SL	L1	PART No.	Фd1	ФD1	SL	L1	PART No.
13	20	5.00	5.50	5130130	30	38	5.70	6.30	5130300
13	23	7.30	8.00	5130131	30	38	7.00	7.70	5130301
14	22	5.70	6.30	5130140	30	40	7.00	7.70	5130302
14	24	7.30	8.00	5130141	30	40	7.50	8.30	5130303
15	23	5.70	6.30	5130150	30	42	10.00	11.00	5130304
16	24	5.70	6.30	5130160	30	45	8.00	8.80	5130305
16	26	7.30	8.00	5130161	30	45	11.40	12.50	5130306
18	24	5.00	5.50	5130180	32	40	5.70	6.30	5130320
18	26	5.70	6.30	5130181	32	40	6.00	6.60	5130321
18	28	7.30	8.00	5130182	32	42	6.30	6.90	5130322
19	29	7.30	8.00	5130190	32	42	7.30	8.00	5130323
20	28	5.50	6.00	5130200	32	47	11.40	12.50	5130324
20	28	5.70	6.30	5130201	35	43	5.70	6.30	5130350
20	28	6.50	7.20	5130202	35	43	6.50	7.20	5130351
20	30	7.30	8.00	5130203	35	45	8.00	8.80	5130352
20	32.7	9.50	10.50	5130204	35	45	10.00	11.00	5130353
22	30	5.70	6.30	5130220	35	47	10.00	11.00	5130354
22	32	7.30	8.00	5130221	35	50	11.40	12.50	5130355
24	30	5.00	5.50	5130240	36	44	5.70	6.30	5130360
24	32	7.00	7.70	5130241	36	46	7.30	8.00	5130361
25	33	5.70	6.30	5130250	36	51	11.40	12.50	5130362
25	35	7.30	8.00	5130251	38	50	7.00	7.70	5130380
25	40	10.00	11.00	5130252	40	48	5.70	6.30	5130400
28	35	6.50	7.20	5130280	40	50	7.30	8.00	5130401
28	36	5.70	6.30	5130281	40	50	10.00	11.00	5130402
28	38	7.30	8.00	5130282	40	52	10.00	11.00	5130403

Фd1	ФD1	SL	L1	PART No.	Фd1	ФD1	SL	L1	PART No.
40	55	10.00	11.00	5130404	55	65	11.00	12.10	5130551
40	55	11.40	12.50	5130405	55	70	11.00	12.10	5130552
42	50	6.50	7.20	5130420	55	75	14.50	16.00	5130553
45	53	7.30	8.00	5130450	56	66	10.00	11.00	5130560
45	55	7.30	8.00	5130451	56	71	11.40	12.50	5130561
45	55	8.00	8.80	5130452	56	76	14.60	16.00	5130562
45	55	10.00	11.00	5130453	60	68	7.00	7.70	5130600
45	60	11.40	12.50	5130454	60	68	11.40	12.50	5130601
45	65	11.40	12.50	5130455	60	68	13.00	14.50	5130602
48	60	10.00	11.00	5130480	60	70	7.30	8.00	5130603
50	58	8.00	8.80	5130500	60	70	10.50	11.60	5130604
50	60	7.30	8.00	5130501	60	70	12.00	13.20	5130605
50	60	7.50	8.30	5130502	60	72	9.00	9.90	5130606
50	60	10.00	11.00	5130503	60	72	10.00	11.00	5130607
50	60	11.40	12.50	5130504	60	75	13.50	14.90	5130608
50	62	9.50	10.50	5130505	60	80	12.00	13.20	5130609
50	63	10.00	11.00	5130506	60	80	14.00	15.40	5130610
50	65	11.40	12.50	5130507	63	73	5.50	6.00	5130630
50	70	14.60	16.10	5130508	63	75	8.70	9.60	5130631
52	62	7.30	8.00	5130520	63	78	11.40	12.50	5130632
53	63	7.30	8.00	5130530	63	83	14.50	16.00	5130633
54	63.5	6.80	7.50	5130540	64	80	12.00	13.20	5130640
54	63.5	9.50	10.50	5130541	65	73	7.00	7.70	5130650
54	66.7	9.50	10.50	5130542	65	75	10.00	11.00	5130651
54	69.9	12.70	14.00	5130543	65	85	12.00	13.20	5130652
55	65	7.30	8.00	5130550	65	85	15.00	16.50	5130653
Фd1	ФD1	SL	L1	PART No.	Фd1	ФD1	SL	L1	PART No.
68	88	15.00	16.50	5130680	90	100	11.40	12.50	5130900
70	80	11.40	12.50	5130700	90	105	11.40	12.50	5130901
70	82	8.70	9.60	5130701	90	110	12.00	13.20	5130902
70	82	9.50	10.50	5130702	90	110	14.50	16.00	5130903
70	85	9.50	10.50	5130703	94	108.5	12.70	14.00	5130940
70	85	11.40	12.50	5130704	95	105	11.40	12.50	5130950
70	90	12.00	13.20	5130705	95	110	11.40	12.50	5130951
70	90	14.50	16.00	5130706	100	108	6.50	7.20	5131000
73	80	7.00	7.70	5130730	100	110	11.40	12.50	5131001
75	83	6.50	7.20	5130750	100	115	11.00	12.10	5131002
75	85	10.50	11.60	5130751	100	120	12.00	13.20	5131003
75	90	11.40	12.50	5130752	100	120	14.50	16.00	5131004
78	86	13.00	14.50	5130780	105	115	10.00	11.00	5131050
80	88	6.50	7.20	5130800	105	120	11.40	12.50	5131051
80	90	11.40	12.50	5130801	105	125	14.50	16.00	5131052
80	92	9.00	9.90	5130802	108	127	15.90	17.50	5131080
80	95	11.40	12.50	5130804	110	120	10.50	11.60	5131100
80	100	9.50	10.50	5130805	110	125	11.40	12.50	5131101
80	100	12.00	13.20	5130806	110	130	12.00	13.20	5131102
80	100	13.50	14.80	5130807	110	130	14.50	16.00	5131103
80	100	15.00	16.50	5130808	110	135	18.20	20.00	5131104
82	92	10.00	11.00	5130820	115	130	11.40	12.50	5131150
85	95	9.50	10.50	5130850	120	135	11.40	12.50	5131200
85	100	9.50	10.50	5130851	120	140	15.00	16.50	5131201
85	100	12.00	13.20	5130852	125	135	11.40	12.50	5131250
85	105	14.50	16.00	5130853	125	140	11.40	12.50	5131251
