Products Description
DFG120-9 PTFE dust rings
Material: PTFE + Carbon fiber
Advantages:
● No stick-slip effect
● High temperature resistance
● Good chemical resistance
● Low cost
● Easy installation
KZT PTFE Dust rings are an essential component of many industrial machines, as they help to prevent damage to critical components such as piston seals and anti-wear rings. By preventing cylinder oil from mixing with foreign particles, these rings ensure that seals remain intact and can continue to provide reliable service for a long time.
KZT PTFE Dust rings are able to work in combination with other components. For example, they work together with anti-wear and piston ring seals to provide a comprehensive sealing solution that helps to keep the piston and rod moving smoothly. This type of system is particularly important in applications where machinery is subjected to heavy loads or frequent use, as it helps to prevent wear and tear.
PTFE Dust rings are designed to work seamlessly with metal bushings. This is important because it helps to prevent damage to the piston and rod due to impurity immersion - a common problem in many industrial settings. By providing a protective barrier between the piston and rod and the harsh environment they operate in, these dust rings help to ensure that machinery can continue to operate smoothly and efficiently over time.
KZT PTFE Dust rings are an important component of many industrial machines, providing essential protection against wear and tear. By working in combination with other components such as anti-wear and piston ring seals, as well as metal bushings, they help to ensure that machinery remains in good working order for longer.
So if you're looking for a reliable solution to seal and protect your machinery, KZT PTFE Dust rings are definitely worth considering.
Production process:
Operating conditions
|
Maximum speed |
2.0m/sec |
|
Temperature range |
-55℃ + 220℃ |
|
Maximum pressure |
≤60 MPa |
|
55*50*6.3 |
95*87*9.5 | 125*117*8 | 145*137*9.5 |
|
65*60*6.3 |
100*92*6 | 125*117*9.5 | 150*142*8 |
|
70*62*12 |
100*95*14.8 | 130*122*8 | 150*142*9.5 |
|
75*67*12 |
105*97*6 | 130*122*9.5 | 160*152*9.5 |
|
80*72*11.8 |
105*97*9.5 | 130X122X8 | 165*157*6 |
|
80*72*4 |
110*102*6 | 135*127*6 |
170*162*8 |
|
80*72*6 |
110*102*9.5 | 135*127*8 |
170*162*9.5 |
|
80*75*6 |
115*107*6 | 135*127*9.5 |
175*167*6 |
|
85*80*6 |
115*107*9.5 | 140*132*6 |
180*172*8 |
|
90*62*6 |
120*112*6 | 140*132*8 |
180*172*9.5 |
|
90*82*14.8 |
120*112*8 | 140*132*9.5 |
190*182*9.5 |
|
90*82*9.5 |
120*112*9.5 | 145*137*6 |
200*192*9.5 |
|
95*87*6 |
125*117*6 | 145*137*8 |
215*207*9.5 |
Typical Application
● Excavators
● Presses
● Mobile hydraulics
● Standard cylinders
● Forklifts
● Loaders
Our service and advantage
● Strict quality control system
● Quick response and delivery
● Factory direct prices
● Customized designs are available
Our exhibition
PTC, BAUMA, Hannover Messe etc.
Packing & Delivery
Thermal shrinkage film
By Express (FedEx, UPS, DHL, TNT, EMS, etc. )
--- Advantage: Fast (takes about 7 - 10 days in the delivery), door to door
This is especially useful for urgent shipments that need to reach their destination quickly. Though express delivery is a little expensive, it is worth the cost if time is a crucial factor.
By Air Transportation
--- Advantage: Fast (takes about 8 - 12 days), a little cheaper than Express.
Though it takes a little longer than express delivery, at around 8-12 days, it is still relatively quick. Additionally, air transportation is a little cheaper than express delivery. The only downside is that the receiver has to collect the goods from the airport.
By Sea (Ocean ) Transportation
--- Advantage: Much cheaper than Express or Air transportation.
Sea transportation is an excellent option for individuals and businesses that need to transport goods across long distances. With its cost savings and global coverage, it's an attractive alternative to other transportation methods.
